Product Details
- 200Ω differential inputs and 100Ω outputs
- Dual VVA+VGA with output RMS detectors
- SPI configurable VGA gain range
- 24dB gain range for each VVA
- Switchable dual inputs for VGA2
- Power-down feature
- Supply voltage: +4.75V to +5.25V
- Total supply current: 145mA
- 5mm x 5mm, 32-VFQFPN package
- -40 °C to +105 °C exposed pad operating temperature range
The F1280 is a highly integrated 0.001MHz to 1200MHz dual VVA+VGA with integrated RMS detectors. The two independently controlled VVA+VGAs each provide 24dB of gain range with four different selectable gain ranges. The VGA gain ranges and switchable VGA2 inputs are controlled through an SPI interface with a 10MHz maximum clock operating frequency.
- Wireless infrastructure
- Medical devices
- General RF
